GE GDF510PGR Plastic Interior Dishwasher

1

2

GDF510PGR/PSR

GE^® Plastic Interior Dishwasher with Front Controls

DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)

ELECTRICAL RATING

24"

Typical

23-3/4"

Voltage AC................................................................120

Hertz..........................................................................60

Total connected load amperage................................6.6

Calrod^® heater watts max................................800/500

For use on adequately wired 120-volt, 15-amp circuit

having 2-wire service with a separate ground wire.

This appliance must be grounded for safe operation.

29-7/8"

INSTALLATION INFORMATION: Before installing,

consult installation instructions packed with product

for current dimensional data.

33-3/8" MIN.

27-1/2"

adj to

34-5/8" MAX.

4" (toekick)

This Wall Area

must be Free

of Pipes or

wires

24"

Min.

33-1/2" to 34-3/4"

Underside of

Countertop

4"

to Floor

Plumbing and Electric Service

Must Enter Inside This Area

Cabinets

Square

and

6"

Plumb

Figure A

24"

Min.

Listed by

Underwriters

Laboratories

For answers to your Monogram, Café, GE Profile^™ or GE Appliances product

questions, visit our website at geappliances.com or call GE Answer Center^®

Service, 800.626.2000.

™

Specification Revised 12/21

VIEW FULL SCREEN PDF MANUAL

General	Details
Name	GE GDF510PGR Plastic Interior Dishwasher
Make	GE
Language	English
Filetype	PDF (Download)
File size	0.17 MB

Download PDF

(1 votes, average: 5.00 out of 5)

Loading...

• ALL DISHWASHER INSTRUCTIONS & USER MANUALS
• GE

GE GDF510PGR Plastic Interior Dishwasher Overview

Summary of Contents

• Page 1: GDF510PGR/PSR GE Plastic interior dishwasher with front controls Electrical rating: Voltage AC: 120 Hertz: 60 Total connected load amperage: 6.6 Calrod heater watts max: 800/500 This appliance must be grounded for safe operation. Installation information: Before installing, consult installation instructions packed with product for current dimensional data. Plumbing and electric service must enter inside this area. Listed by Underwriters Laboratories.
• Page 2: Reliable performance ensures clean and dry dishes with every cycle. Dry Boost™ outperforms standard heated dry dishwashers for hard-to-dry items. Water leak sensor prevents potential overflows for greater peace of mind. High wash performance provides a complete wash without pre-rinsing. Choose your cycle with options for heavy wash, normal wash, rinse, and 1-hour wash. Upper and lower rack capacity offers loading flexibility and total wash coverage. This ENERGY STAR® dishwasher saves energy without sacrificing features. The Piranha™ hard food disposer prevents clogging and ensures clean dishes. Large capacity accommodates 14 place settings and large dishware. The quiet operation at 59 dBA provides powerful cleaning without disturbances.
