Mini-wok multi-crown burner
Adjusting the taps
1. Set the control elements to the minimum power
level and pull them out.
2. To access the bypass screw, use the tip of the
screwdriver to push down on the flexible rubber
holder.
Never remove the sealing ring. Sealing rings pre-
vent liquids and dirt from finding their way into the
appliance and impairing its ability to function prop-
erly.
3. When adjusting the bypass screws (M) with a slot-
.
‒ A: Firmly tighten the bypass screws.
‒ B: Turn the bypass screws until the gas flow
from the burners is correct.
Replacing the nozzles
1. Remove all pan supports, burner caps and distrib-
utors.
2. Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
Ensure that the nozzle does not become detached
during removal or fastening.
Reinstalling the appliance
▶ Install the appliance components in reverse order.
Checking if equipment is working
1. Check that turning the rotary knob between the
position for maximum power and the position for
minimum power does not cause the burner to go
out or result in backfire.
2. If the gas flow from the burner is not correct:
, check whether the nozzle
and the bypass screw are correct.
‒ Tighten or loosen the bypass screw until the
gas flow from the burner is correct.
Documenting the gas type conversion
▶ Attach the sticker showing the new gas type near
to the rating plate.
