¡ The appliance must only be installed on an oven
with forced ventilation. Check the dimensions of
the oven in the installation instructions for the
oven.
¡ Connect the appliance to a fixed gas pipe or a
flexible metal pipe.
¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the ap-
pliance is installed (e.g. a drawer) and must not
be routed through any spaces which might be-
come obstructed.
¡ If you install an oven underneath the hob, the work
surface thickness may differ from the dimensions
given in these instructions. Take note of the in-
formation in the oven installation instructions.
¡ If you install an exhaust air fan or an extractor
hood, refer to the installation instructions for these.
Always observe the minimum vertical distance to
the hob.
¡ Gas connection elbow on the appliance: R 1/2.
¡ Do not move or twist the gas connection elbow.
Connection to gas cylinder or liquid gas tank
▶ If the flame is large or unstable, check that the
regulator of the gas cylinder or liquid gas tank is
working properly.
Note: You can install an overpressure safety device
that limits or cuts off the gas supply if the regulator
of the gas cylinder or liquid gas tank fails.
Preparing the units
¡ Make a cut-out in the worktop with the required di-
mensions.
¡ Any panel that is attached closer to the built-in
niche than the specified clearance must be made
of non-combustible material. Always maintain a
distance of at least 5 mm between the panel and
the appliance. Maximum clearances for the panel:
30 mm thickness x 70 mm height.
Spare parts for gas connection
If the country's regulations allow, you can obtain the
gas connection parts from the technical customer
service.
¡ Seal the cut surfaces of wooden work surfaces
with a special glue seal to protect them from mois-
ture.
Gas connection R 1/2
¡ If there is no built-in oven underneath the hob, in-
sert a non-flammable separator (e.g. metal or ply-
wood) at a distance of 10 mm from the hob. This
prevents access to the underside of the hob. The
distance from the intermediate floor to the mains
connection for the appliance must be at least 10
mm.
Gas connection G 1/2
1. Replace the gas connection elbow on the appli-
ance with the gas connection elbow G 1/2 sup-
plied in the accessory bag.
2. Insert the seal between the gas connection of the
appliance and the gas supply.
Positioning the appliance
Note: Do not use silicone to bond the appliance to
the worktop.
Electrical connection
¡ This appliance is type Y: The connection cable
must only be replaced by technical customer ser-
vice and not by the user. The cable type and the
minimum cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
1. Position the hob with the upper side facing down
on a flat, stable surface.
2. Apply the adhesive seal supplied to the lower
edge of the hob. The adhesive seal prevents the
penetration of liquids.
¡ The power cable must only be replaced with a
cable from the original manufacturer. This is avail-
able from after-sales service.
¡ Do not use extension cables or multiple socket
strips.
¡ Only connect appliances that are fitted with a plug
to a correctly installed socket with protective earth
conductor.
3. Screw the brackets supplied into the specified po-
sition so that they can turn freely.
4. Turn the hob around and insert it into the recess.
Insert the hob in the front of the recess.
5. Turn the brackets and tighten them fully.
¡ Connect the appliance to a fixed installation and
set up appropriate isolating switches in accord-
ance with the installation regulations.
The position of the brackets depends on the work-
top thickness.
¡ BN: Brown
¡ BU: Blue
¡ GN/YE: Green and yellow
Removing the appliance
1. Disconnect the appliance from the electricity and
gas connections.
2. Unscrew the brackets and proceed in reverse or-
Converting the gas type
der.
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
Connecting the gas
Observe the country-specific guidelines.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
CAUTION ‒ Risk of explosion!
A gas leakage may cause an explosion.
▶ If any connection is handled, check the seal.
shows the
right combination for the relevant burner and gas
type.
¡ Arrange the gas connection so that the shut-off
valve is accessible.
Economy burner
¡ Ensure that the information on the rating plate re-
garding the gas type and gas pressure complies
with the local connection conditions.
Standard-output burner
High-output burner
5
