GE Monogram UDT165SIVII 18 Inch Dishwasher

1

2

3

UNIVERSAL 18" DISHWASHER

UDT165SIVII

OVERALL DIMENSIONS

17 3/4" (45.1)

27"

(68.6)

32 1/2" min

5 3/8" min

34 5/8" max

(82.6 - 87.9)

7 1/2" max

(13.7 - 19.1)

Toe kick

height

FRONT VIEW

23 1/2" (59.7)

SPECIFICATIONS

32 1/2" min

34 5/8" max

17 3/4" (45.1 cm)

Overall Width

(82.6 - 87.9)

Height at rear

(Includes tub trim)

32 1/2" (82.6 cm) Min

Overall Height

34 5/8" (87.9 cm) Max

23 1/2" (59.7 cm)

Overall Depth

4 1/4"

(Includes 3/4" panel)

(10.8)

Door Clearance

23 1/8" (58.7 cm)

8 Place Settings

SIDE VIEW

Overall Dishwasher

Capacity

17 3/4" (45.1)

Minimum Cabinet

Width

17 3/4" (45.1 cm)

23 5/8" (60.0 cm)

Minimum Cabinet

Depth

17 3/4" (45.1 cm) Min

18" (45.7 cm) Max

Cutout Width

Cutout Height

32 1/2" (82.6 cm) Min

34 3/4" (88.3 cm) Max

2" (5.1)

Electrical

Requirements

8.9 A

TOP VIEW

No more than

12' (3.7 m)

Hose Length

23 1/8"

(58.7)

120 V, 60 Hz,

15 or 20 amp circuit

OPEN DISHWASHER

DOOR SHOWING

DOOR CLEARANCE

Voltz/Hertz/Amps

Shipping Weight

77 lb (35 kg)

2" min (5.1)

clearance

to wall

2" min (5.1)

clearance

to wall

Dimensions in parentheses are in

centimeters unless otherwise noted.

Product Specification Revised 5/23

VIEW FULL SCREEN PDF MANUAL

General	Details
Name	GE Monogram UDT165SIVII 18 Inch Dishwasher
Make	GE MONOGRAM
Language	English
Filetype	PDF (Download)
File size	0.28 MB

Download PDF

(1 votes, average: 5.00 out of 5)

Loading...

• ALL DISHWASHER INSTRUCTIONS & USER MANUALS
• GE MONOGRAM

GE Monogram UDT165SIVII 18 Inch Dishwasher Overview

Summary of Contents

• Page 1: Universal 18 dishwasher Overall dimensions Specifications Overall width Overall height Overall depth Minimum cabinet width Minimum cabinet depth Electrical requirements Shipping weight
• Page 2: Universal 18 dishwasher installation notes include important specifications for proper setup. The dishwasher drain hose must be no more than 12 feet in length for proper drainage. A reduced-height installation beneath a 34 countertop can be accomplished with a minimum underside height of 32 1/2. Water and electrical connections must be routed through the back wall in the shaded area. To prevent siphoning, an air gap or high drain loop must be used. A custom panel installation template is available from GE Parts and Accessories. The custom door panel and handle should be secured to the dishwasher before installation begins. A complete panel installation instructions template is provided, with a maximum panel weight of 8 lbs. For planning purposes, the template can be ordered in advance. Complete panel installation instructions are included on the template.
• Page 3: Universal 18 dishwasher features and benefits include a custom panel model designed for personalization with customer-supplied cabinet-compatible panel and custom handle. It has hidden, integrated electronic controls that allow easy activation of wash cycles: heavy wash, light wash, and Auto Sense. The three-level wash system provides effective, yet quiet cleaning power. Nylon gray racks with ball-tipped tines offer plenty of space and loading flexibility. The Piranha hard food disposer grinds food into small particles that are washed away. It operates at 47 DBA, creating a peaceful kitchen environment while delivering powerful wash performance.
