Hotpoint H8I HT59 LS UK Dishwasher

1

2

3

4

5

6

Daily Reference Guide

EN

Before using the appliance carefully read

Safety and Installation Instructions. More information about your

product available on website: docs.hotpoint.eu

THANK YOU FOR BUYING A HOTPOINT PRODUCT. In order

to receive a more complete assistance, please register your

appliance on: www.hotpoint.eu/register

After installation, please remember to remove all transport

protection parts from the dishwasher.

CONTROL PANEL

1

2

3

4

5

6

7

8

9

10 11

12

13

14

15

16

1. ON-OFF/Reset button with indicator light

2. Eco program button with indicator light

3. Rapid program button with indicator light/ Soak program - 3 sec. press

4. Delicates program button with indicator light/ Self-Clean program - 3 sec. press

5. Auto programs buttons with indicator lights - Auto Intensive 65°/ Auto Mixed 55°/

Auto Fast 50°

6. Salt reservoir empty indicator light

7. Rinse Aid reservoir empty indicator light

8. Display

9. Program number and remaining time indicator

10. Closed water tap indicator light

11. DESCALE indicator light

12. Extra options buttons with indicator lights - Half Load / Silent / Sani Rinse

13. Zone Wash 3D option button with indicator light

14. Extra Dry option button with indicator light / Settings - 3 sec. press

15. Delay option button with indicator light

16. START/Pause button with indicator light

FIRST TIME USE

SETTING MENU

Water Hardness Table

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings (Extra Dry ) button for 3 seconds, until you hear a

beep and the display shows„SEt”.

°dH

German degrees

°fH

French degrees

°Clark

English degrees

Level

1 (Soft)

3. After one second the first available setting (letter„h”) will be displayed.

4. Press Autoprograms /Extra options buttons to scroll through the list

0 - 6

7 - 11

0 - 10

11 - 20

21 - 29

30 - 60

61 - 90

0 - 7

8 - 14

2 (Medium)

3 (Average)

4 (Hard)

of available settings (see table below), then press START/Pause

view and change the value of the currently selected setting.

to

12 - 16

17 - 34

35 - 50

15 - 20

21 - 42

43 - 62

5. Press Auto programs /Extra options to change the value, then press

START/Pause to save the new value.

6. To change another setting, repeat points 2 and 5.

7. Press ON-OFF or wait 30 seconds to exit the menu.

5 (Very hard)

WATER SOFTENING SYSTEM

VALUES

(Default - in bold)

LETTER

SETTING

Water softener automatically reduces water hardness, consequently preventing

scale buildup on the heater, contributing also to better cleaning efficiency.

This system regenerates itself with salt, therefore it is required to refill

the salt container when empty. The frequency of regeneration depends

on the water hardness level setting - regeneration takes place once per 4-6

Eco cycles with the water hardness level set to 3. The regeneration process

occurs at the beginning of the cycle with additional fresh water.

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”)

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

1 | 2 | 3 | 4 | 5

0 | 1 | 2 | 3 | 4 | 5

•

•

•

Single regeneration consumes: ~3L of water;

Takes up to 5 additional minutes for the cycle;

Consumes below 0.005kWh of energy.

ActiveDry (see “OPTIONS AND FUNCTIONS”)

“1”= On, “0”= Off

1 | 0

1 | 0

1 | 0

Light on the floor (see “OPTIONS AND FUNCTIONS”)

“1”= On, “0”= Off

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be

filled when the RINSE AID REFILL indicator light in the control panel is lit.

1. Open the dispenser

Sound

“1”= On, “0”= Off

Factory Settings

B

by

pressing and pulling up the

tab on the lid.

Press START/Pause to restore to the factory

default all the values of the settings included

in the settings menu.

-

2. Pour in the rinse aid (max.110

ml), making sure it does not

overflow from the dispenser.

If this happens, clean the spill

immediately with a dry cloth.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

A

B

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

•

•

•

It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satisfied with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 6 levels can be set according to the dishwasher model.

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set

a mid-range number (4-5).

It is important to set the water hardness.

Salt must be filled when the SALT REFILL indicator light

trol panel is lit.

on the con-

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see figure) and fill the salt reservoir

right up to its edge (approximately 0,5 kg); it is not un-

usual for a little water to leak out.

3. Only the first time you do this: fill the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce

the detergent into the dry dispenser D only. Place the amount of

detergent for pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser D, there are indica-

Run a program every time as soon as you completed refilling the salt

reservoir to avoid corrosion.

Setting the water hardness

D

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the

To allow the water softener to work in a perfect way, it is essential that the water

hardness setting is based on the actual water hardness in your house. This in-

formation can be obtained from your local water supplier. The factory setting is

“3”. See „WATER HARDNESS TABLE”. To change, follow instructions in section

“SETTING MENU”.

C

dispenser and close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling

it up until the closing device is secured in place.

The detergent dispenser automatically opens up at

the right time according to the program.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

Only use salt that has been specifically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches off.

If the salt container is not filled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Use of salt is recommended with any type of dishwasher detergent.

1
