KitchenAid KDFE204KPS Dishwasher
INSTALLATION INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the nstallation, User Maintenance and Operating
Instructions printed and online, before installing this appliance.
WARNING
To access the expanded and additional Installation, User
Maintenance and Operating Instructions online, refer to the Quick
Start Guide provided with the product.
Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
For a grounded, cord-connected dishwasher:
The dishwasher must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for
electric current. The dishwasher is equipped with a cord
having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with all local
codes and ordinances.
Doing so can result in serious injury or cuts.
LOCATION REQUIREMENTS
Drill hole locations – new construction
335/8
"
4"
WARNING: Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service representative if
you are in doubt whether the dishwasher is properly
grounded. Do not modify the plug provided with the
dishwasher; if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
minimum
(85.4 cm)
minimum
(10.2 cm)
6¼"
(15.9 cm)
A
B
C
3"
(7.6 cm
21"
(53.4 cm)
2"
(5.1 cm)
D
24"
For a permanently connected dishwasher:
The dishwasher must be connected to a
grounded metal, permanent wiring system, or an
equipment-grounding conductor must be run
with the circuit conductors and connected to the
equipment-grounding terminal or lead on the
dishwasher.
(62.0 cm)
A. Optional location
B. Preferred location
C. Measured from the lowest point on the underside of the
counter top. May be reduced to 335/8" minimum (85.4 cm)
minimum by removing the feet and perforated area of insulation
(blanket) on dishwasher.
D. Minimum, measured from narrowest point of opening.
NOTE: Shaded areas of cabinet walls show where utility
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the recommended tools and parts before starting
installation.
connections may be installed.
The power-supply receptacle for the appliance shall be installed
in a cabinet or on a wall adjacent to the under counter space in
which the appliance is to be installed.
Be sure when the appliance is installed or removed to reduce
the likelihood of damage to the power cord.
Moisture Barrier Tape: (on some models)
Drill a 11" (3.8 cm) drain hose hole in the side or rear of
cabinet, depending on location of drain hose routing and drain
hose connection location.
NOTE: Moisture Barrier tape is recommended if installing a
dishwasher under a wooden or laminate countertop. The models
with automatic door open system will have this part included in
the literature package.
Drill a 1/2" (1.27 cm) water supply hose hole in the side or rear of
cabinet, depending on location of water supply routing and
connection location
WARNING: To reduce the risk of electric shock, fire, or injury to
persons, the installer must ensure that the dishwasher is
completely enclosed at the time of installation.
NOTE: Be sure to purchase only Whirlpool factory-certified parts
and accessories for your appliance. Your installation may require
additional parts. To order, refer to the contact information
referenced in your Quick Start Guide.
Drill a 11" (3.8 cm) electrical conduit hole in the right-hand side
or rear of cabinet.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
dishwasher.
Failure to do so can result in back or other injury.
2
