CMA DISHMACHINES CMA-180VL Dishwasher
2.2.4. Straight to corner operation retrofit instructions.
In order to convert machine from straight to corner application,
you will need to relocate the tray track rail from straight to corner
position (see red line on the photo) and then mount it on the tray
track using the same bolts, washers and lock nuts used for straight
application.
MODEL CMA-180VL INSTALLATION & OPERATION Rev. 2.01C
Page
9
